FPM-221W-P4AE 21.5" Full HD Industrial Monitor with P-CAP Touch Control, Direct HDMI Port

  • 21.5" Full HD TFT LED LCD with true-flat touchscreen
  • 16:9 wide screen aspect ratio, increases viewing area by 40%
  • Supports 10-point multi-touch control via USB interface in Windows 7/8/10 OS
  • Slim design enables easy installation
  • Supports various mount options: panel, wall, desktop, and VESA arm
  • Touchscreen with reliable glass surface and P-CAP touch control
  • Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
  • Lockable I/O connectors
Certifications CE CE CE CE CE CE CE
Especificaciones Driver Manual Modelo 3D Descarga

(Impuestos NO incluidos)
Agregar al Carrito Comprar
FPM-221W-P4AE
FPM-221W-P4AE
FPM-221W-P4AE
FPM-221W-P4AE
FPM-221W-P4AE
FPM-221W-P4AE
Agregar al Carrito

Agregado al Carrito

Ir al Carrito

Especificaciones Detalladas

Hardware

  • Certification CB, UL, CE, FCC Class A, CCC, BSMI
  • OS Support Microsoft® Windows Vista, Microsoft® Windows 7, Microsoft® Windows 8,Microsoft® Windows XP, Microsoft® Windows XPe, Microsoft® Windows CE, Linux,Microsoft® Windows 10 LTSB
  • Power Input 12 VDC
  • Video Port HDMI

LCD Display

  • Viewing Angle (H/V°) 178/178
  • Luminance (cd/m2) 250
  • Max. Resolution 1920 x 1080
  • Display Size 21.5"
  • Backlight Life (hrs) 50,000

I/O Interface

  • Power Connector 1 x Lockable DC Jack

Environment

  • Ingress Protection Front Panel IP66
  • Vibration Protection 1 Grms, random
  • Operating Temperature 0~50 °C (32~122 °F)
  • Storage Temperature -20~60 °C (-4~140 °F)
  • Storage Humidity 10~95% RH (non-condensing)

Touchscreen

  • Touch Type PCAP

Mechanical

  • Enclosure Die cast magnesium alloy, Die-casting aluminum
  • Mounting Stand, Wall, VESA, Panel
  • Weight (Net) 6 kg (13.22 lb)
  • Dimension (W x H x D) 558.4 x 349.8 x 56.2 mm
